RCINPOWER SMOOX 2306 PLUS MOTOR 1880/2580KV

$16.79

After the huge success of the 2207 Plus motors, RCINPOWER released these 2306 plus motors (PLUS stands for 0.5mm) so these motors are 2306.5 sizes. The 2580kv motors are Gunmetal colored, and the 1880kv motors are Teal Blue colored.

Motor Kv

Clear

Free Shipping in the US for most orders over $100

SKU: 47210 Category: Motors

Description
Additional information

RCINPOWER SMOOX 2306 PLUS MOTOR 1880/2580KV 10 - RCinpower

RCINPOWER SMOOX 2306 PLUS MOTOR 1880/2580KV

After the huge success of the 2207 Plus motors, RCINPOWER just released these 2306 plus motors (PLUS stands for 0.5mm) so these motors are 2306.5 sizes.

2580kV – Gun Metal

1880kV – Teal Blue

Check out our other RCinpower motors!

Specifications:

Configuration: 12N14P

Stator Diameter: 23mm

Stator Length: 6.6mm

Shaft Diameter: 4mm ( Hollow)

Idle Current(10V): 1.35A @ 1880KV ; 1.95A @ 2280KV ; 2.3A@2580KV

Max. Con. Power (5S): 900W @ 1880KV; 850W @ 2280KV ; 1100W@2580KV

Internal Resistance: 49mΩ@ 1880KV ; 40mΩ @ 2280KV ; 30mΩ @2580KV

Max. Current(5s): 36A @ 1880KV ; 40A @2280KV ; 55A @ 2580KV
Cable Length: 15cm
Motor Dimension(Dia*Len):29×30.5mm
Weight: 33g ( 3cm wire)

Package includes:

1x SmooX 2306 Plus Motor Pick Your Color & KV
1x Motor Nut

Weight	0.05 lbs
Dimensions	2 × 2 × 2 in
Brand	RCinpower
Motor Kv	1880Kv, 2580Kv
Motor Type	Mini Quad Motors
Motor Size	23XX
Color	Gunmetal, Teal
