FrSky XJT Module

Check out all of our FrSky products, radio receivers, and modules!

Features:

• Advanced Continuous Channel Shifting Technology (ACCST SYSTEM) achieves highly reliable links in interference-rich environments.
• Smart Port – Full Duplex communication
• Easy to bind and instant link-up
• Excellent reboot times
• All channels failsafe
• Quick response
• Very smooth servo movement
• The alarm on events of the receiver (low battery voltages, poor reception, etc.)
• Error-free link, by using a 48bits CRC algorithm
• Firmware upgradeable

Compatibility:

• V8 Series: (Non-Telemetry receivers)
  • V8FR-II, V8R7-II, V8R4-II, VD5M
• D Series: (Telemetry receivers)
  • D8R, D8R-II, D8R-II Plus, D8RSP, D8R-XP, D6FR, D4FR, D4R-II, etc.
• X Series: (Telemetry receivers)
  • X8R, X6R, X4R, etc.
• LR Series: (Long Range receivers)
  • L9R

Compatible with the following transmitters:
JR: 347, 388, 783, U8, PCM10, PCM10S, PCM10SX, PCM10IIS, 8103, J9303, MX-22, MX-24S, PX, 9XII, Eurgle 9X, Turnigy 9X and more.

Specifications:

• Operating Voltage Range: 6.0V-15.0V
• Operating Current: 140mA (@6V), 80mA (@12V)
• Output Power: ≤ 100mW
